Pilot FX for panels test

The new Pilot FX Next> Series platform revolutionizes in-circuit and functional panel test, bridging the gap between Bed of Nails and Flying Probe test. Pilot FX Next> Series is the right compromise in productivity and flexibility, designed specifically to test panels. Thanks to an its revolutionary mechanical architecture, the system optimizes and shares test resources, including special, often costly, instrumentation. Pilot FX Next> Series is not only about resource optimization, or innovation (there is nothing similar on the market today) or automating test; it is, above all, a breakthrough in the test philosophy.     A “flying” bed of nails for panels Pilot FX Next> Series system provides the capability to share test resources, moving a small, low-cost fixture from one board to another, effectively eliminating the need to duplicate them in the system. The mechanical architecture of the system allows the test head, which carries the fixture, to rotate in order to accommodate any configuration of panel layout, and the Pilot FX Next> Series is fully implementable in an automated production line, making it an innovative and efficient part of the process. The Pilot FX Next> Series system features all of the core performances and benefits of the Seica VIP test platform, including hardware and software scalability. Traceability The Pilot FX Next> Series uses a state-of-the-art color camera which, in addition to fiducial centering, is able to acquire the serial number of each single board within the panel. An integrated marker is available to mark the tested boards, according to user-defined rules. Thanks to Seica’s wide experience in high-volume production test, the VIVA test software is able to communicate with external databases, enabling full integration of the Pilot4D FX system into the user’s own production management environment. Scalability The Pilot FX Next> Series has a 19’’ rack for the integration of external instrumentation, ensuring resource scalability for new applications. The integration of dedicated OBP programming modules, sensors for LED test applications, Boundary Scan test, and communication management via standard protocols (for example: CAN BUS, LIN), are only some of the possible capabilities that can be implemented.
